Product code: #ALL-004968

SDT3E410-8P-MB-A-PV1 8მპ+4მპ TiOC PTZ მართვადი კამ. 10x ოპტ. გად. IP66, IR 70მ, Warm light 30მ

Dahua

SDT3E410-8P-MB-A-PV1 8მპ+4მპ TiOC PTZ მართვადი კამ. 10x ოპტ. გად. IP66, IR 70მ, Warm light 30მ

1 582.10 ₾

VAT included

  • In stock
1 582.10 ₾

VAT included

  • In stock
Quantity
1

Installation request
PaymentBy cardBy bank transfer
Datasheet (opens in a new tab)

Storage

8 cameras like this, 30 days: 22.4 TB

8 cameras, with margin: 105.2 W

Calculate exactly

Compare with similar

Full comparison

Description

The Dahua SDT3E410-8P-MB-A-PV1 is a PTZ network camera that combines a panoramic overview channel and a detail channel in one unit. The overview channel has a 1/2.8" CMOS sensor and a 2.8 mm lens with a field of view of H 180° / V 47°, at a maximum resolution of 5376 × 1520. The detail channel has a 1/2.8" CMOS sensor and a 4–40 mm lens with 10x optical zoom, at a maximum resolution of 2560 × 1440.

The camera supports infrared, white light and dual illumination for low-light scenes. It also offers line crossing and intrusion detection, with a warning light and audio warning as active deterrence. It is rated IP66 and works from -30 to +60 °C.

Key features:

  • 8 MP panoramic overview channel (F1.6) and a detail channel (F1.6-F3.6) with 10x optical zoom and 300 PTZ presets
  • Pan from 0° to 345° and tilt from -10° to +90°
  • Detail channel with 120 dB WDR; overview channel with DWDR
  • Compression: H.265+, H.265, H.264+, H.264 and MJPEG at 25/30 fps
  • Built-in microphone, 1 audio input and 1 audio output channel, 1 alarm input and 1 alarm output
  • Micro SD card slot (512 GB), plus FTP/SFTP and NAS storage
  • RJ-45 (100 Base-T) port; powered by 12 VDC or PoE+ (802.3at), with 6 kV surge protection; works with DMSS and SmartPSS Lite

Features in action

1 demos

  • Line Crossing

    Line Crossing Detection

    The camera detects when a person or vehicle crosses a virtual line in the set direction and triggers an instant alert.

Bought together

−5%

The kit is ready, adjust it as you need

Camera + 2 accessories

Kit · 1 672.19 ₾1 761.19 ₾

Kit −89 ₾

Specifications 39

Open the spec sheet PDF(opens in a new tab)

Camera

Image Sensor
Overview channel: 1/2.8" CMOS;
Detail channel: 1/2.8" CMOS
Max Resolution
Overview channel: 5376 (H) × 1520 (V);
Detail channel: 2560 (H) × 1440 (V)
Megapixels
8 MP
Form Factor
Panoramic
Characteristics
Microphone, microSD

Lens

Focal Length
2.8 mm, 4–40 mm
Lens
2.8 mm, 4–40 mm
View Type
Multi-lens, Panoramic
Optical Zoom
10 ×
PTZ Presets
300
Pan / Tilt Range
Pan: 0° to 345°;
tilt: -10° to +90°
Aperture
Overview channel: F1.6;
Detail channel: F1.6-F3.6
Field of View
Overview channel: H 180° / V 47°;
Detail channel: H: 58°–11.3°;
Detail channel: V: 33.1°–6.4°;
Detail channel: D: 66.4°–12.8°

Image & Video

Supplement light
Infrared (IR), White light, Dual light
Min. Illumination
Overview: 0.005 lux@F1.6 (Color);
Overview: 0.0005 lux@F1.6 (B/W);
Overview: 0 lux (illuminator on);
Detail: 1 s–1/30,000 s;
Detail: 0.005 lux@F1.6 (Color);
Detail: 0.0005 lux@F1.6 (B/W);
Detail: 0 lux (illuminator on)
IR Range
30 m (98.4 ft)
Day / Night
Day/Night (auto IR-cut)
WDR
Overview channel: DWDR;
Detail channel: 120 dB
Frame Rate
25/30 fps
Compression
H.265+, H.265, H.264+, H.264, MJPEG

Audio

Audio
Overview channel: PCM, G.711A, G.711Mu, G.726, MPEG2-Layer2, G.722.1, G.729;
Detail channel: none

Network

Network Interface
RJ-45 (100 Base-T)
Storage
Micro SD card (512 GB);
FTP/SFTP;
NAS

Power & Protection

Power Supply
12 VDC, 3 A PoE+(802.3at)
IP / IK Rating
IP66
Power Consumption
25 W
Surge Protection
6 kV

Outputs & Audio

Audio Input
1 channel;
LINE IN (bare wire);
or built-in microphone
Audio Output
1 channel;
LINE OUT (bare wire);
or built-in speaker

Smart & Features

Features
Line Crossing, Intrusion Detection
Active Deterrence
Warning Light, Voice Warning
Alarm Input
1 (on/off input: 0–5 VDC)
Alarm Output
1 channel

Connectivity

Compatible software
DMSS, SmartPSS Lite

Compliance

Certifications
CE

Physical

Operating humidity
≤ 95 %
Operating Temperature
-30 … +60 °C (-22 … 140 °F)
Dimensions
181.7 × 238.8 × 140.3 mm (7.15 × 9.4 × 5.52 in)
Weight
2.17 kg (4.78 lb)
