Product code: #ALL-000186

Network recorder Dahua NVR2104HS-4KS3

Dahua

Network recorder Dahua NVR2104HS-4KS3

250 ₾

VAT included

  • In stock
250 ₾

VAT included

  • In stock
Quantity
1

Installation request
PaymentBy cardBy bank transfer
Datasheet (opens in a new tab)

Storage

For 4 cameras, 30 days: 5.6 TB · 1 × 6 TB

Calculate exactly

Compare with similar

Full comparison

Description

The Dahua NVR2104HS-4KS3 is a network video recorder (NVR) for IP camera systems. It has 4 IP channels and records from IP signal sources at resolutions from 1 MP (720p) up to 12 MP, using H.265+, H.265 and H.264+ compression.

The recorder has 1 HDD slot that supports a disk of up to 20 TB. It outputs video through HDMI and VGA, includes SMD and perimeter protection AI functions, and works with the DMSS and SmartPSS Lite applications. The compact housing measures 260 × 47.6 × 232.5 mm and weighs 850 g.

Key features:

  • 4 channels and 4 IP channels, with recording resolutions of 1 MP (720p), 2 MP (1080p), 3 MP, 4 MP, 5 MP, 6 MP, 8 MP (4K) and 12 MP
  • H.265+, H.265 and H.264+ compression, with ONVIF support
  • Incoming and outgoing stream of 80 Mbps each, through 1 × RJ-45 10/100 Mbps network interface; 0 PoE ports
  • 1 HDD slot for a disk of up to 20 TB; playback of up to 4 channels at a time
  • Decoding with AI off: up to 1 × 12 MP@30 fps, or 6 × 1080p@30 fps; with AI on: up to 1 × 8 MP@30 fps, or 4 × 1080p@30 fps
  • 1× HDMI and 1× VGA video outputs, 1 × RCA audio input and 1 channel RCA audio output, plus 1 × USB 2.0 on the front and 1 × USB 2.0 on the rear
  • 12 VDC, 1.5 A power supply with 10 W power consumption; operating temperature from -10 to +55 °C (14 to 131 °F) and humidity from 10 to 93 %; CE certified

Bought together

−5%

The kit is ready, adjust it as you need

Recorder + 3 accessories

Kit · 2 345.49 ₾2 469.49 ₾

Kit −124 ₾

Specifications 32

Open the spec sheet PDF(opens in a new tab)

Network

Network Interface
1 × RJ-45, 10/100 Mbps
Incoming Bandwidth
80 Mbps
Outgoing Bandwidth
80 Mbps
ONVIF
Yes

Power & Protection

Power Supply
12 VDC, 1.5 A
Power Input
12 VDC, 1.5 A
Power Consumption
10 W

Recording

Decoding capability
AI off: 1 × 12 MP@30 fps;
1 × 8 MP@30 fps;
2 × 6 MP@30 fps;
2 × 5 MP@30 fps;
3 × 4 MP@30 fps;
6 × 1080p@30 fps;
AI on: 1 × 8 MP@30 fps;
1 × 6 MP@30 fps;
1 × 5 MP@30 fps;
2 × 4 MP@30 fps;
4 × 1080p@30 fps
Recorder Type
NVR
Channels
4
IP Channels
4
Recording Resolution
1 MP (720p), 2 MP (1080p), 3 MP, 4 MP, 5 MP, 6 MP, 8 MP (4K), 12 MP
Signal Support
IP
Recorder Compression
H.265+, H.265, H.264+
Playback
Up to 4 channels

Storage

HDD Bays
1
Max. Capacity per Disk
up to 20 TB

Outputs & Audio

Video Output
1× HDMI, 1× VGA
Audio Input
1 × RCA
Audio Output
1 channel RCA

Smart & Features

AI Features
SMD, Perimeter Protection
Alarm Input
None (2 channels optional)
Alarm Output
None (optional: 1 × 12 V 1 A)

Ports & PoE

PoE Ports
0

Connectivity

Compatible software
DMSS, SmartPSS Lite
USB Port
Front: 1 × USB 2.0;
rear: 1 × USB 2.0

Compliance

Certifications
CE

Physical

Operating humidity
10 … 93 %
Form Factor / Chassis
Compact
Operating Temperature
-10 … +55 °C (14 … 131 °F)
Dimensions
260 × 47.6 × 232.5 mm (10.24 × 1.87 × 9.15 in)
Weight
850 g (29.98 oz)
