Product code: #ALL-002446

Media converter MC111CS, WDM 10/100Mbps Fast Ethernet Media Converter

Omada

Media converter MC111CS, WDM 10/100Mbps Fast Ethernet Media Converter

  • Fiber TypeSingle-mode
  • Max Distance20 km
119 ₾

VAT included

  • In stock
119 ₾

VAT included

  • In stock
Quantity
1

PaymentBy cardBy bank transfer
Datasheet (opens in a new tab)

Compare with similar

Full comparison

Description

The Omada MC111CS is a WDM 10/100Mbps Fast Ethernet media converter. It links a copper Ethernet connection to a single-mode fiber connection, using 1 RJ45 port on the electrical side and 1 SC fiber optic port on the optical side.

The converter adopts WDM technology, transmitting at 1550nm and receiving at 1310nm over a single fiber, and extends fiber distance up to 20km. It follows the IEEE 802.3i and IEEE 802.3u standards and is powered by a 9V/0.6A input.

Key features:

  • 1× 100M SC/UPC fiber port and 1× 10/100M RJ45 port with Auto MDI/MDIX
  • WDM wavelengths of 1550nm Tx and 1310nm Rx, with 9/125μm single-mode fiber and a maximum distance of 20km
  • Half/Full-Duplex transfer mode for the FX port
  • Copper cabling: UTP category 3, 4, 5 or EIA/TIA-568 100Ω STP for 10BASE-T, and UTP category 5, 5e or EIA/TIA-568 100Ω STP for 100BASE-T, each up to 100m
  • PWR and Link/Act LED indicators
  • Power consumption of 1.3 W, with operating temperature of 0 … +50 °C (32 … 122 °F) and operating humidity of 10%~90% non-condensing
  • Dimensions of 94.5 × 73 × 27 mm (3.72 × 2.87 × 1.06 in), with FCC, CE and RoHS compliance

Specifications 26

Open the spec sheet PDF(opens in a new tab)

Power & Protection

Power Input
9V/0.6A
Power Consumption
1.3 W

Ports & PoE

RJ45 ports
11 RJ45 jack
Optical Ports
1 SC fiber optic

Optical

Connector Type
SC
Fiber Type
Single-mode
Wavelength TX
1550nm
Wavelength RX
1310nm
Max Distance
20 km
Fiber Core
9/125μm

Physical

Operating Temperature
0 … +50 °C (32 … 122 °F)
Dimensions
94.5 × 73 × 27 mm (3.72 × 2.87 × 1.06 in)

Full specification

Manufacturer data, 14 parameters

Media Converter & Module

Standards and Protocols
IEEE 802.3i, IEEE 802.3u
Basic Function
Adopts WDM technology;
Half/Full-Duplex transfer mode for FX port;
Extends fiber distance up to 20km
Interface
1× 100M SC/UPC port;
1× 10/100M RJ45 port (Auto MDI/MDIX)
Wavelength
1550nm Tx/1310nm Rx
WDM TX
1550nm
WDM RX
1310nm
Network Media, 10BASE-T
UTP category 3, 4, 5 cable (maximum 100m);
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media, 100BASE-T
UTP category 5, 5e cable (maximum 100m);
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media, 100BASE-FX
Single-mode Fiber
LED
PWR, Link/Act
Safety & Emission
FCC, CE, RoHS
Storage Temperature
-40℃~70℃ (-40℉~158℉)
Operating Humidity
10%~90% non-condensing
Storage Humidity
5%~90% non-condensing
